ROLAIR FC1500HS3 1.5HP AIR COMPRESSOR ROL-AIR 4 CFM

Hand Carry Compressor

Features

Pump description

ROLAIR Quality, Heavy-Duty, Cast-Iron Cylinder, Single Stage, Ball Bearings, Filter/Silencer, Stainless Steel Reed Valves, and Splash Lubrication To Ensure Longer Pump Life

 Motor description

1.5 HP, 3400 RPM, Overload Protection with Manual Reset, 115 Volt, 60 Hz, Heavy-Duty, Industrial Grade with Ball Bearings for Greater Durability

 Standard equipment

Pressure Switch with On/Off Lever, Regulator w/Air Line Pressure Gauge, 6 oz. Crankcase Pre-filled with Oil, 95/125 PSI Operating Pressure, Factory Tested, Safety Relief Valve

Specifications

HORSE POWER :

·         1.5 HP

CFM DISPLACED @ 90 PSI :

·         7.8 CFM

CFM DELIVERED @40/90 PSI :

·         4.24/4.00 CFM

PUMP/MOTOR RPM :

·         3400 RPM

OVERLOAD PROTECTION :

·         Yes (Manual Reset Standard)

LUBRICATION TYPE :

·         Splash Lubrication

PUMP OIL CAPACITY :

·         6 Ounces

REED VALVE SYSTEM :

·         Yes (Standard)

NUMBER OF CYLINDERS :

·         1

TANK CAPACITY :

·         2.5 Gallons

L x W x H :

·         20 x 9 x 18

DECIBEL RATING :

·         79 dBA

SHIPPING WEIGHT :

·         43 lbs.
