ROLAIR FC250090L 2.5HP - 24-Gall Upright - 5.1CFM

Hand Carry Compressor

Features

Pump description

ROLAIR Quality, Single Stage, Ball Bearings, Cast-Iron Cylinder, Stainless-Steel Reed Valves and Splash Lubrication Ensure Longer Life.

Motor description

2 HP, 3400 RPM, S1-Rated for Continuous Duty, Low-Amp Draw, Overload Protection with Manual Reset, 115 Volt, 60 Hz, Heavy-Duty/Industrial-Grade with Ball Bearings for Greater Durability.

 Standard equipment

100% Duty-Cycle Motor, Start/Stop Pressure Switch, Air Line Regulator, Tank Pressure Gauge, Easy-to-Maneuver 24-Gallon Tank, Wheels and Handle, Safety-Relief Valve, Intake Filter/Silencer, Initial 12-oz. Oil Fill Included.

Specifications

HORSE POWER

·         2.0 HP

CFM DISPLACED @ 90 PSI

·         10.1 CFM

CFM DELIVERED @40/90 PSI

·         5.40/5.10 CFM

PUMP/MOTOR RPM

·         3400 RPM

OVERLOAD PROTECTION

·         Yes (Manual Reset Standard)

LUBRICATION TYPE

·         Splash Lubrication

PUMP OIL CAPACITY

·         12 Oz

REED VALVE SYSTEM

·         Yes (Standard)

NUMBER OF CYLINDERS

·         1

TANK CAPACITY

·         24 Gallons

L x W x H :

·         23 x 28 x 44

DECIBEL RATING

·         80 dBA

SHIPPING WEIGHT

·         160 lbs.
