ROLAIR V5180K30B-19 Two-Stage, Cast-Iron Cylinders,5HP, 18 CFM, 1800 RPM, 60 Hz, Open Drip-Proof Motor. MAGNETIC STARTER

Electric Stationary Compressor

Features

Pump description

Two-Stage, Cast-Iron Cylinders, Aluminum Head and Crankcase for Faster Heat Dissipation, Ball Bearings, Splash Lubricated, Bearing Inserts on Connecting Rods, Swedish Lammelar Reed Valves, Oil Sight Gauge, Low RPM's to Ensure Long Life and Trouble-Free Performance.

Motor description

1800 RPM, 60 Hz, Open Drip-Proof Motor. Single Phase Models Available in 208 and 230 Volt. Three Phase Models Available in 208, 230, and 460 Volt.

 Standard equipment

Pressure Switch - Start/Stop Operation,110-135 PSI Settings, On/Off Switch, Automatic Unloading Device for Loadless Starts, Heavy-Duty Shut-Off Valve, Pressure Gauge, 0-200 PSI in 5 lb. Graduations, Safety Relief Valve - ASME Approved, V-Belt Drive, Intake Filter/Silencer w/Replaceable Element, Totally Enclosed Steel Belt Guard.

Optional Equipment

Magnetic Starter, Automatic Tank Drain, Low Oil Shut Down, Level-Rite Mounts, Vibration Pads, Dual Controls, Head Unloader, Refrigerant Air Dryer, Air Cooled Aftercoole

Specifications

HORSE POWER

·         5 HP

CFM DISPLACED @ 175 PSI

·         23.1 CFM

CFM DELIVERED @ 100 PSI

·         N/A

CFM DELIVERED @ 175 PSI

·         18.0 CFM

MOTOR RPM

·         1800 RPM

PUMP RPM

·         900 RPM

PUMP OIL CAPACITY

·         47 Ounces

SINGLE OR TWO STAGE

·         Two Stage (2 Cylinder)

REED VALVE SYSTEM

·         Yes (Standard)

TANK CAPACITY

·         Unit pictured-80 Gallon (Refer to detailed image for model specific capacities)

L x W x H

·         30 x 24 x 77

DECIBEL RATING

·         Unavailable

SHIPPING WEIGHT

·         Unit pictured-495 lbs. (Refer to detailed image for model specific weights)
