ROLAIR VT25BIG 2.5HP - 5.3 Gall Cart - 6.5CFM

Hand Carry Compressor

Features

Pump description

Low Speed ~ Quiet, ROLAIR Quality, Cast-Iron Cylinder, Single Stage, Ball Bearings, Stainless-Steel Reed Valves and Splash Lubrication Ensure Longer Life

Motor description

2.5 HP, 3400 RPM, S1-Rated for Continuous Duty, Low-Amp Draw, Overload Protection with Manual Reset, 115 Volt, 60 Hz, Heavy-Duty/Industrial Grade with Ball Bearings for Greater Durability.

 Standard equipment

00% Duty-Cycle Motor, Heavy Duty Wheels for Greater Jobsite Mobility, Start/Stop Pressure Switch with On/Off Lever, Fold Down Handle for Easy Storage/Low Profile, User-Friendly Control Panel Including Gauges, Two Quick-Disconnect, Safety-Relief Valve, Intake Filter Silencer, 13.8 Amp Motor, Initial 10-Oz. Oil Fill Included.

Specifications

HORSE POWER

·         2.5 HP

CFM DISPLACED @ 90 PSI

·         9.3 CFM

CFM DELIVERED @40/90 PSI

·         6.90/6.50 CFM

PUMP/MOTOR RPM

·         3400 RPM

OVERLOAD PROTECTION

·         Yes (Manual Reset Standard)

LUBRICATION TYPE

·         Splash Lubrication

PUMP OIL CAPACITY

·         10 Oz

REED VALVE SYSTEM

·         Yes (Standard)

NUMBER OF CYLINDERS

·         1

TANK CAPACITY

·         5.3 Gallons

L x W x H

·         29 x 22 x 44

DECIBEL RATING

·         90 dBA

SHIPPING WEIGHT

·         108 lbs
