SIMPSON STRONG-TIE AT-XP10 9.4 OZ AT-XP W/NOZZLE

NOTE: FOR INFORMATIONS ON PRODUCT SPECIFICATIONS

SEE DEATAILED IMAGES

AT-XP® Fast-Curing Anchoring Adhesive for Cracked and Uncracked Concrete

The latest innovation from Simpson Strong-Tie, AT-XP® anchoring adhesive has been formulated for high-strength anchorage of threaded rod and rebar into concrete under a wide range of conditions. AT-XP adhesive dispenses easily in cold or warm environments with little to no odor, and when mixed properly is a teal color for easy post-installation identification.

Code-listed per IAPMO UES ER-263 in accordance with ICC-ES AC308 and IBC 2009 requirements for cracked and uncracked concrete in static or seismic conditions, AT-XP anchoring adhesive has demonstrated superior performance in reduced-temperature testing (14°F (-10°C)), has NSF/ Standard 61 certification (43.2 in2/1000 gal), and is made in the USA.

FEATURES

·         AT-XP adhesive has passed the demanding adverse condition tests of ICC-ES AC308 pertaining to reduced temperature, elevated temperature and long-term creep

·         Code-listed per IAPMO UES ER-263

·         Can be used under static and seismic loading conditions in both cracked and uncracked concrete

·         Low-odor formula dispenses easily at below-freezing temperatures without the need to warm cartridge

·         Cures in substrate temperatures as low as 14°F in 24 hours or less

·         Easiest hole-cleaning method – no power brushing needed

·         When properly mixed, adhesive will be a teal color for easy identification

·         Available in 9.4 oz., 12.5 oz. and 30 oz. cartridges for jobsite versatility

USES / APPLICATIONS

·         Threaded rod anchoring into concrete

·         Rebar doweling into concrete

·         Suitable for horizontal, vertical and overhead applications

CODE REPORTS

NEW IAPMO UES ER-263 (Cracked and Uncracked Concrete)

NEW IAPMO UES ER-281 (Masonry)

NEW City of Los Angeles RR25960 (Cracked and Uncracked Concrete)

NEW City of Los Angeles RR25966 (Masonry)

NEW Florida Statewide Product Approval FL 16230

NSF/ANSI Standard 61 (PDF) (43.2 in2/1000 gal)

INSTALLATION

IMPORTANT For installation instructions, SEE DEATAILED IMAGES

When the concrete temperature is at or below freezing, ensure any holes drilled in advance are free of frost or ice.

See below for Installation Information and Additional Data for Threaded Rod and Rebar in Normal-Weight Concrete.

SHELF LIFE

·         12 months from date of manufacture in unopened cartridge.

STORAGE CONDITIONS

·         For best results store between 32°F–80°F (0°C– 27°C). Partially used cartridges can be stored for a limited time by leaving nozzle in place. To re-use, attach new nozzle.

COLOR

·         Resin — black-green, initiator — white

·         When properly mixed, adhesive will be a uniform teal color.

CLEAN UP

·         Uncured material — Wipe up with cotton cloths. If desired, approved solvents, such as ketones (MEK, acetone, etc.), lacquer thinner, or adhesive remover can be used. DO NOT USE SOLVENTS TO CLEAN ADHESIVE FROM SKIN. Take appropriate precautions when handling flammable solvents. Solvents may damage surfaces to which they are applied. Cured material — Chip or grind off surface.

GEL TIME

·         Under the ASTM C 881 test method, 3.5 minutes for a 60g mass at 73°F (23°C)

AT-XP® Adhesive Cartridge System

1.       Cartridge estimation guides are available here.

2.       Detailed information on dispensing tools, mixing nozzles and other adhesive accessories is available here.

3.       Use only Simpson Strong-Tie® mixing nozzle in accordance with Simpson Strong-Tie instructions. Modification or improper use of mixing nozzle may impair AT-XP adhesive performance.

4.       One AMN19Q nozzle and one nozzle extension is supplied with each cartridge.

CHEMICAL RESISTANCE

Very good to excellent against distilled water and inorganic acids. Fair to good against organic acids and alkalis, inorganic alkalis and many organic solvents. Poor against ketones. For more detailed information, contact Simpson Strong-Tie or see Technical Bulletin T-A-CHEMRES14 .

SUGGESTED SPECIFICATIONS

Anchoring adhesive shall be a two-component, high-solids, acrylic-based system supplied in manufacturer's standard cartridge and dispensed through a static-mixing nozzle supplied by the manufacturer. The adhesive anchor shall have been tested and qualified for performance in cracked and uncracked concrete per ICC-ES AC308. Adhesive shall be AT-XP® adhesive from Simpson Strong-Tie, Pleasanton, CA. Anchors shall be installed per Simpson Strong-Tie instructions for AT-XP adhesive. For additional questions, contact Simpson Strong-Tie.
