SIMPSON STRONG-TIE ET-HP22 ET-HP® Anchoring Adhesive "RED BRICK"

ET-HP® Anchoring Adhesive

ET-HP® is a two-component, high-solids epoxy system for use as a high-strength, non-shrink anchor grouting material. Resin and hardener are dispensed and mixed simultaneously through the mixing nozzle.

Note: The ET product has been renamed ET-HP to highlight the addition of testing in accordance with AC308 and performance data being presented in Strength Design format. No formulation or manufacturing changes have been made to the product.

Features:

·         ET-HP has passed the demanding adverse-condition tests of ICC-ES AC308 pertaining to elevated temperature and long-term sustained load

·         Code-listed under the current IBC/IRC for cracked and uncracked concrete per ICC-ES ESR-3372

·         Code-listed under the current IBC/IRC for masonry per IAPMO UES ER-241

·         Suitable for use under static and seismic loading conditions in cracked and uncracked concrete

·         Cure times: 24 hours at 80°F, 72 hours at 50°F

·         Easy hole-cleaning procedure – no power brushing required

·         Suitable for use in damp or wet anchor sites

·         When properly mixed, adhesive will be a uniform gray color

·         Available in 22 oz. and 56 oz. cartridges for application versatility

·         Made in the USA

Applications:

·         Threaded rod and rebar doweling into concrete and masonry

·         Suitable for horizontal, vertical and overhead applications

·         Multiple DOT listings, refer to www.strongtie.com DOT for current approvals

Codes: ICC-ES ESR-3372 (concrete); IAPMO UES ER-241 (masonry); ICC-ES ESR-3638 (URM); City of Los Angeles RR25120; ASTM C 881 (Type I and IV, Grade 3, Class C)

Shelf Life: 24 months from date of manufacture in unopened container

Storage Conditions: For best results store between 45°F–90°F. To store partially used cartridges, leave hardened nozzle in place. To re-use, attach new nozzle.

ET-HP Cartridge Systems

Cure Schedule

For water-saturated concrete (including damp and water-filled holes), the cure times must be doubled.
