WOODSTOCK W1706 SHOP FOX® 14" Bandsaw - 1 H.P.

1 HP 14" Bandsaw

We took the most popular bandsaw size and added many features found only on much larger and more expensive machines. Features such as extruded-aluminum fence and rails, quick-release blade tension, miter gauge, upper and lower ball bearing blade guides, enclosed cabinet stand, hinged wheel covers, 4" dust port, and a 1 HP motor are all standard. And, with its cast -iron frame and table, this bandsaw will be a reliable shop fixture for many years to come. An optional 6" extension block kit (D3348) is also available. CSA certified meeting CSA and UL standards!

Specifications

• Motor: 1 HP, 110V/220V, prewired 110V, single-phase, TEFC, 1725 RPM, 11A/5.5A
• Blade size: 93-1/2" (1/8" to 3/4" wide)
• Precision-ground cast-iron table size: 14" x 14" x 1-1/2"
• Cutting capacity (throat): 13-1/2"
• Max. cutting height: 6"
• Table height above floor: 43"
• Blade speeds: 1800 & 3100 FPM
• Cast-iron frame and wheels
• Table tilt: 45° right, 10° left
• Precision-ground cast-iron table
• Cast-iron blade wheels
• Deluxe extruded-aluminum fence
• Ball-bearing blade guides
• Footprint: 18"W x 15-1/2"D
• Heavy-duty cabinet-type stand with storage space
• Quick-change blade release/tensioning
• Upper and lower ball bearing blade guides
• All ball bearing construction
• 4" dust port
• Includes one 3/8" blade, fence and miter gauge
• Fence scale with magnifying window
• Approximate shipping weight: 275 lbs.
