WOODSTOCK W1820 SHOP FOX® 10" 3 H.P. Cabinet Table Saw with Riving Knife and Long Rails
$0.00
Out of stock
SKU
1231747
10" 3 HP Cabinet
Table Saw with Riving Knife and Long Rails
Every part of this saw says quality and performance. From
the heavy-duty cast-iron trunnions, 3 HP motor and triple-belt drive to the
massive cast-iron table and wings, this table saw is built to last a lifetime.
You'll also appreciate the camlock T-fence, included riving knife, heavy cast
handwheels, magnetic switch, T-slot miter gauge with fence extension and flip
stop and 4" dust collection port. Features an extra wide 49" rip
capacity—more than enough to rip to the center of a standard sheet of plywood,
a long extension table with adjustable legs, square steel tubing frame, and
dimensionally stable extension table. Certified to CSA and UL standards!
Specifications
|
Motor |
3 HP, 230V, single-phase,
12.8A |
|
Blade tilt |
0°-45° left |
|
Arbor size |
5/8" |
|
Arbor speed |
4300 RPM |
|
Max. depth of cut @ 90° |
3-1/8" |
|
Max. depth of cut @ 45° |
2-3/16" |
|
Max. rip capacity |
49" |
|
Max. dado width |
13/16" |
|
Cast-iron table size |
27" x 40-1/4" |
|
Table size with extension |
27" x 74" |
|
Port |
4" dust port |
|
Table height from floor |
34" |
|
Includes |
10" x 40-tooth
carbide-tipped blade and extended-reach push stick |
|
Overall size |
82"L x 45-1/2"W x
40"H |
|
Approximate shipping weight |
567 lbs. |
Features
- Precision-ground and polished cast-iron table and wings
- Massive cast-iron trunnions
- Miter gauge with adjustable T-slot and anodized fence with
extension and flip stop
- Camlock fence with HDPE face
- Powder-coated finish
- Includes standard & dado table inserts
- Quick-release blade guard with independent-lifting sides and
retractable pawls
- Wide-span easy-glide T-fence system
- Knurled knobs for fine fence adjustments
- Nylon runners inside fence head assembly
- Sloped inner cabinet floor for efficient dust transport
- Accessory hooks on cabinet
- Magnetic switch with thermal overload protection
| Availability | Out of Stock |
|---|---|
| Manufacturer | WOODSTOCK |
| Manufacturer Sku | W1820 |
